IEC62133/UN38.3 26650 8S2P 24V 6Ah lifepo4 battery pack for trolling motor
| Item | Rating | Note | |
3.1 Capacity | Typical | 6Ah | Discharge: 0.2CmA |
| Minimum | 5.7Ah | ||
| 3.2 Nominal Voltage | Average 25.6V | ||
| 3.3 AC Impedance Resistance≤3mΩ | ≤280mΩ | ||
| 3.4 Discharge Cut-off Voltage | 20.0V | ||
| 3.5 Charge Current | 1.2A | Standard Charge | |
| 3.6 Charge Voltage | 29.2V | ||
| 3.7 Charge time | Approx 6h | Charge: 0.2CmA | |
| 3.8 Max. Charge Current | 6A | ||
| 3.9 Continuous Discharge Current | 6A | ||
| 3.10. Max discharge current | 12A | ||
| 3.11 Weight | Approx 1.4kg | ||
| 3.12 Operating Temperature | Charge | 0~+45ºC | |
| Discharge | -20~60ºC | ||
| 3.13 Storage Temperature | less than1 month | -20~45ºC | Recommended storage temperature: 20ºC,at the shipment state |
